TECHNICAL SPECIFICATION

• Rated Voltage : 250VAC, 50/60Hz
• Rated Current : 16AX
• Recommended wire size : 2.5mm² - 4mm²
• Isolating Gap Contact : 3mm nominal
• Contact Material : Silver-Nickel Alloy
• Operating Temperature : -5°C to +40°C
• IP Rating : IP2X
• No. of operations : 40,000 operation at 16 Amp.
• Dimensions : 86 x 86 x 10mm (WxHxD)
• Fix Center : 60.3 mm
• Fix Screw : M3.5 x 0.6 x 30mm±
• Mounting box : >25mm depth /  R1150, flush mounting, plastic (80 x 80 x 48.4mm) (WxHxD) / M1247, flush mounting, metal (79 x 73 x 47mm) (WxHxD)
• Comply to standards : BS EN 60669-1 / IEC 60669-1 / GB/T 16915.1
